Inspur NF5288M5 Server – Inspur NF Rack Servers

Inspur has launched the world  s densest and most powerful AI server AGX-2 (model name: Inspur NF5288M5) with 300GB/s high speed NVIDIA NVLink to connect 8 high performance GPU accelerators within 2U space. This server is immensely important for AI training and HPC applications where it can provide 200 times higher performance than the traditional dual-CPU servers. The flexible and scalable design can achieve dual-system horizontal expansion to 16 GPU structure which extremely useful to cater for different computing scenarios.

Quick Spec

Table 1 shows the quick spec.

Product Details

Inspur NF5288M5 provides these features:

Extreme computing density

Utilizes P100 s Linpack s floating point computing power to achieve 29.33TFLOPS, 2.47 times that of NF5288M4, which also utilizes P100.

Easily allow a 42U rack s cluster s peak performance to rise above 1 PFLOPS (one quadrillion floating point operations per second).

Make inter-GPU bandwidth as high as 300 GB/s and allow for little to no lag, allowing an over 60% increase in the efficiency of parallel GPU.

Incorporated two latest Intel Xeon Scalable Processor and 16 2666 MHz speeds based memory sticks.

Ultimate flexible design

Allows one or two CPU to manage 8 GPU or achieve scale-up up to 16GPU by way of expanding box by GPU. PCIe I / O, 8 U.2 slots, or up to 4 network interface cards of 100Gbps InfiniBand provided by the server can flexibly adjust topology according to the calculation.
