Dell PowerEdge R750xs 8LFF Server Overview

The Dell EMC PowerEdge R750xs, with 3rd generation Intel Xeon Scalable processors, is purposefully designed with distinctive, customer-defined requirements to deliver enterprise performance for scale-out environments.

Table 1 shows the 3 configuration of Dell R750xs 8LFF Server.

ConfigurationProcessorMemoryHard DrivePower Supply
Dell 2U R750 4310 8LFF ServerIntel Xeon 431032G2T SAS 10K800W
Dell 2U R750 5317 8LFF ServerIntel Xeon 531732G2T SAS 10K800W
Dell 2U R750 6330 8LFF ServerIntel Xeon 633032G2T SAS 10K1400W

Quick Spec

Table 2 shows the quick spec of Dell R750xs server.

SeriesDell EMC PowerEdge R750xs
ProcessorUp to two 3rd Generation Intel Xeon Scalable processors with up to 32 cores
Memory• 16 DDR4 DIMM slots, supports RDIMM 1 TB max, speeds up to 3200 MT/s

• Supports registered ECC DDR4 DIMMs only

Storage controllers• Internal controllers: PERC H345, PERC H745, PERC H755, PERC H755N, HBA355i, S150

• Internal Boot: Internal Dual SD Module, Boot Optimized Storage Subsystem (BOSSS1): HWRAID 2 x M.2 SSDs, USB

• External PERC (RAID): PERC H840, HBA355e

Drive BaysFront bays:

• 0 drive bay

• Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 128 TB

• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB

• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB

• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB

• Up to 16 x 2.5-inch (SAS/SATA) + 8 x 2.5-inch (NVMe) (HDD/SSD) max 184.32 TB

Rear bays:

• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 15.36 TB

Power Supplies• 600 W DC/240 V

• 600 W Platinum AC/100 – 240 V

• 800 W DC/240 V

• 800 W Platinum AC/100 – 240 V

• 1100 W DC/-48–(-60) V

• 1100 W DC/240 V

• 1100 W Titanium AC/100 – 240 V

• 1400 W DC/240 V

• 1400 W Platinum AC/100 – 240 V

Product Details

Dell EMC PowerEdge R750xs is a 2U, dual-socket, feature-optimized server with an ideal selection of CPU, I/O, and storage performance for scale-out environments. With it, you can:

• Add additional power and cores: Up to two 3rd generation Intel Xeon Scalable processors, up to 32 cores per socket

• Accelerate in-memory workloads: Up to 16 DDR4 RDIMMS, 3200 MT/sec

• Improve throughput, reduce latency: With up to 5 PCIe Gen4 slots, OCP 3.0 for network cards, and SNAP I/O support

• Include flexible storage: Up to 12x 3.5” SAS/SATA HDDs or SSDs; or up to 16x 2.5” SAS/SATA HDDs or SSDs, and 8 NVMe drives

• Enable virtualization, medium VM density or VDI, and software-defined storage node workloads

Figure 1. Front view of the R750xs system

Front view of the dell r750xs system

Figure 2. Rear view of the R750xs system

Rear view of the dell r750xs system

Compare to Similar Items

Table 3 shows the R750 vs R750xs.

SeriesDell EMC PowerEdge R750Dell EMC PowerEdge R750xs
ProcessorUp to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processorUp to two 3rd Generation Intel Xeon Scalable processors with up to 32 cores
Memory• 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s

• Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max

• Supports registered ECC DDR4 DIMMs only

• 16 DDR4 DIMM slots, supports RDIMM 1 TB max, speeds up to 3200 MT/s

• Supports registered ECC DDR4 DIMMs only

Storage controllers• Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N

• Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB

• Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB

• External PERC (RAID): PERC H840, HBA355E

• Internal controllers: PERC H345, PERC H745, PERC H755, PERC H755N, HBA355i, S150

• Internal Boot: Internal Dual SD Module, Boot Optimized Storage Subsystem (BOSSS1): HWRAID 2 x M.2 SSDs, USB

• External PERC (RAID): PERC H840, HBA355e

Drive BaysFront bays:

• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB

• Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB

• Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB

• Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB

Rear bays:

• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB

• Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB

Front bays:

• 0 drive bay

• Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 128 TB

• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB

• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB

• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB

• Up to 16 x 2.5-inch (SAS/SATA) + 8 x 2.5-inch (NVMe) (HDD/SSD) max 184.32 TB

Rear bays:

• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 15.36 TB

Power Supplies• 800 W Platinum AC/240 mixed mode

• 1100 W Titanium AC/240 mixed mode

• 1400 W Platinum AC/240 mixed mode

• 2400 W Platinum AC/240 mixed mode

• 600 W DC/240 V

• 600 W Platinum AC/100 – 240 V

• 800 W DC/240 V

• 800 W Platinum AC/100 – 240 V

• 1100 W DC/-48–(-60) V

• 1100 W DC/240 V

• 1100 W Titanium AC/100 – 240 V

• 1400 W DC/240 V

• 1400 W Platinum AC/100 – 240 V



Dell R750xs 8LFF Server Spcification

Dell EMC PowerEdge R750xs Specification

ProcessorUp to two 3rd Generation Intel Xeon Scalable processors with up to 32 cores
Memory• 16 DDR4 DIMM slots, supports RDIMM 1 TB max, speeds up to 3200 MT/s

• Supports registered ECC DDR4 DIMMs only

Storage controllers• Internal controllers: PERC H345, PERC H745, PERC H755, PERC H755N, HBA355i, S150

• Internal Boot: Internal Dual SD Module, Boot Optimized Storage Subsystem (BOSSS1): HWRAID 2 x M.2 SSDs, USB

• External PERC (RAID): PERC H840, HBA355e

Drive BaysFront bays:

• 0 drive bay

• Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 128 TB

• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB

• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB

• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB

• Up to 16 x 2.5-inch (SAS/SATA) + 8 x 2.5-inch (NVMe) (HDD/SSD) max 184.32 TB

Rear bays:

• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 15.36 TB

Power Supplies• 600 W DC/240 V

• 600 W Platinum AC/100 – 240 V

• 800 W DC/240 V

• 800 W Platinum AC/100 – 240 V

• 1100 W DC/-48–(-60) V

• 1100 W DC/240 V

• 1100 W Titanium AC/100 – 240 V

• 1400 W DC/240 V

• 1400 W Platinum AC/100 – 240 V

Cooling OptionsAir cooling
Fans• Standard fans/High performance Silver fans/High performance Gold fans

• Up to six hot swap fans

Dimensions• Height – 86.8 mm (3.41 inches)

• Width – 482 mm (18.97 inches)

• Depth – 707.78 mm (27.85 inches) – without bezel

721.62 mm (28.4 inches) – with bezel

Form Factor2U rack server
Embedded Management• iDRAC9

• iDRAC Service Module

• iDRAC Direct

• Quick Sync 2 wireless module

BezelOptional LCD bezel or security bezel
OpenManage Software• OpenManage Enterprise

• OpenManage Power Manager plugin

• OpenManage SupportAssist plugin

• OpenManage Update Manager plugin

MobilityOpenManage Mobile
Integrations and ConnectionsOpenManage Integrations

• BMC Truesight

• Microsoft System Center

• Red Hat Ansible Modules

• VMware vCenter and vRealize Operations Manager

OpenManage Connections

• IBM Tivoli Netcool/OMNIbus

• IBM Tivoli Network Manager IP Edition

• Micro Focus Operations Manager

• Nagios Core

• Nagios XI

Security• Cryptographically signed firmware

• Secure Boot

• Secure Erase

• Silicon Root of Trust

• System Lockdown (requires iDRAC9 Enterprise or Datacenter)

• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Embedded NIC2 x 1 GbE LOM
Network Options1 x OCP 3.0
GPU OptionsNot supported
PortsFront Ports

• 1 x Dedicated iDRAC Direct micro-USB

• 1 x USB 2.0

• 1 x VGA

Rear Ports

• 1 x USB 2.0

• 1 x Serial (optional)

• 1 x USB 3.0

• 2 x RJ-45

• 1 x VGA (optional for liquid cooling configuration)

Internal Ports

• 1 x USB 3.0 (optional)

PCIeUp to 5 x PCIe Gen4 slots / 1 x PCie Gen3 slots
Operating System and Hypervisors• Canonical Ubuntu Server LTS

• Citrix Hypervisor

• Microsoft Windows Server with Hyper-V

• Red Hat Enterprise Linux

• SUSE Linux Enterprise Server

• VMware ESXi
