Dell PowerEdge R240 1-Way 1U 4-Bay 3.5-inch 14th Generation Rack Server
Compute made simple Dell PowerEdge R240
The Dell EMC PowerEdge R240 is an affordable
single-socket 1U rack server designed for small
businesses and service providers.
Description
Dell PowerEdge R240
• Improved performance due
to 100% more cores
• Scale with 17% more storage
capacity
• Protect your server from malicious
malware with iDRAC9 Enterprise
Server Lockdown modeDesigned for budget-conscious businesses
The Dell EMC PowerEdge R240 designed for dense environments is the ideal solution for budget-conscious businesses.
The R240 offers features to support your demanding and growing business needs.
• Accelerate your business with improved performance due to 100% more cores with Intel® Xeon® E-2200 processors,
11% increase in memory speed, and 20% more PCIe lanes.1
• Harness data growth with up to 4 x 3.5” cabled hard drives.
• Manage operational costs with Multi-Vector cooling which automatically calculates and delivers the proper airflow
needed for optimal cooling.
• Improved performance due
to 100% more cores
• Scale with 17% more storage
capacity
• Protect your server from malicious
malware with iDRAC9 Enterprise
Server Lockdown modeDesigned for budget-conscious businesses
The Dell EMC PowerEdge R240 designed for dense environments is the ideal solution for budget-conscious businesses.
The R240 offers features to support your demanding and growing business needs.
• Accelerate your business with improved performance due to 100% more cores with Intel® Xeon® E-2200 processors,
11% increase in memory speed, and 20% more PCIe lanes.1
• Harness data growth with up to 4 x 3.5” cabled hard drives.
• Manage operational costs with Multi-Vector cooling which automatically calculates and delivers the proper airflow
needed for optimal cooling.
PowerEdge R240 Specification
PowerEdge R240 Specification | |
| Processor | 1 processor from the following: Intel® Xeon® E-2200 product family, Intel Pentium®, Intel Core i3®, Intel Celeron® |
| Operating System | Citrix® XenServer® Microsoft® Windows Server® with Hyper-V (2016 and 2019) Red Hat® Enterprise Linux Ubuntu® Server LTS SUSE® Linux Enterprise Server VMware® ESXi |
| Memory (RAM) | 4 x DDR4 DIMM slots, Supports UDIMM, up to 2666MT/s, 64GB Max. Supports registered ECC |
| Storage | Up to 4 x 3.5 cabled SATA, SAS (optional) or SSD* Up to 4 x 3.5 or 2.5 hot-plug SATA, SAS (optional) or SSD* *available in the hot-plug configuration |
| Storage Controllers | Internal controllers: PERC H730P, H330, HBA330 Software RAID: PERC S140 External controllers: 12Gbps SAS HBA |
| Power Supplies | Single 250W (Bronze) or 450W (Platinum) power supply |
| Ports | Networking Options: 2 x 1GbE LOM Network Interface Controller (NIC) ports Front ports: 1x USB 2.0, 1 x IDRAC micro USB 2.0 management port Rear ports: 2 x USB 3.0, VGA, serial connector |
| Slots | 2 x PCIe Gen 3.0 slots: • One x8 slot low-profile, half-length with x4 slot width • One x16 slot low-p |
| Bezel | Optional security bezel |
| Form Factor | 1U rack server |
| Dimensions and Weight | Chassis width: 434.00mm (17.08 in) Chassis depth: 573.596mm (22.58 in) (3.5” HDD config) Note: These dimensions do not include: bezel, redundant PSU Chassis weight: 12.2 kg (26.89 lb.) |
| Rack Support | ReadyRails™ static rails for tool-less mounting in 4-post |
