Cisco C9300-24S-A – Cisco Catalyst 9300 Switches Series

C9300-24S-A – Cisco Switch Catalyst 9300

Catalyst 9300 24-port 1G SFP with modular uplinks, Network

Add to quote
Category:

Cisco C9300-24S-A Overview

The Cisco Catalyst 9300 Series switches are Ciscos lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industrys most widely deployed switching platform.

Quick Specs

Table 1 shows the Quick Specs.

Product CodeC9300-24S-A
Product DescriptionCatalyst 9300 24 GE SFP Ports, modular uplink Switch
Total 10/100/1000 or Multigigabit copper ports24x 1G SFP
Uplink ConfigurationModular Uplinks
Default AC power supply715W AC
Available PoE powerN/A
Dimensions (H x W x D)1.73 x 17.5 x 17.7 Inches



C9300-24S-A Specification



C9300-24S-A Specification

Total 10/100/1000 or Multigigabit copper ports24x 1G SFP
Uplink ConfigurationModular Uplinks
Default AC power supply715W AC
Available PoE powerN/A
Dimensions (H x W x D)1.73 x 17.5 x 17.7 Inches
Weight16.84 Pounds
Cisco StackWise-480Yes
Cisco StackPowerYes
Default power supplyPWR-C1-715WAC-P/2
Switching capacity208 Gbps
Stacking bandwidth688 Gbps
Forwarding rate154.76 Mpps
Total number of MAC addresses32,000
Total number of IPv4 routes (ARP plus learned routes)32,000 (24,000 direct routes and 8000 indirect routes)
IPv4 routing entries32,000
IPv6 routing entries16,000
Multicast routing scale8000
QoS scale entries5120
ACL scale entries5120
Packet buffer per SKU16 MB buffer for 24- or 48-port Gigabit Ethernet modelst

32 MB buffer for 24 and 48-port Multigigabit

FNF entries64,000 flow on 24- and 48-port Gigabit Ethernet models

128,000 flows on 24-port Multigigabit

DRAM8 GB
Flash16 GB
VLAN IDs4094
Total Switched Virtual Interfaces (SVIs)1000
Jumbo frames9198 bytes
Total routed ports Catalyst per 9300 Series stack448
Wireless bandwidth per switchUp to 96 Gbps on 48-port Gigabit Ethernet model
Mean time between failures – MTBF (hours)284,130
Safety certifications





•UL 60950-1

•CAN/CSA-C222.2 No. 60950-1

•EN 60950-1

•IEC 60950-1

•AS/NZS 60950.1

•IEEE 802.3

Electromagnetic emissions certifications•47 CFR Part 15

•CISPR22 Class A

•EN 300 386 V1.6.1

•EN 55022 Class A

•EN 55032 Class A

•CISPR 32 Class A

•EN61000-3-2

•EN61000-3-3

•ICES-003 Class A

•TCVN 7189 Class A

•V-3 Class A

•CISPR24

•EN 300 386

•EN55024

•TCVN 7317

• V-2/2015.04

•V-3/2015.04

•CNS13438

•KN32

•KN35

•IEC 61000-6-1

•EN 61000-6-1

EnvironmentalReduction of Hazardous Substances

(ROHS) 5
